Frame details & specifications
Cervélo P5 Frameset - Red Hot
The P5 is Cervélo's disc-brake time trial and triathlon platform, raced by Team Jumbo-Visma in its 2023 Giro d'Italia and Tour de France wins. This is the current-generation P5 frameset in the Red Hot colourway, supplied with the aero cockpit, seatpost and integrated storage.
Adjustable Aero Front End
The one-piece front end is simpler to assemble and adjust. Stack can be adjusted up to 40mm, the basebar sits lower to reduce frontal area, and the extensions can be tilted between 0 and 30 degrees.
Room for Wider Tyres
The frame and fork clear tyres up to 34mm on wide rims, which lets you run modern wide aero wheels for lower rolling resistance.
Built-in Storage and Hydration
The frameset comes with aero top tube storage, a stem storage compartment, a rear hydration mount and an aero water bottle with cage, so long-course triathletes can carry nutrition without adding clutter.
Who Is It For?
Triathletes and time triallists who want a dedicated, adjustable race frame and plan to build it with their own groupset and wheels.
Good to Know
Included: frame, Cervélo Bayonet P5 all-carbon fork, Cervélo HB15 carbon aero basebar (38cm), Profile Design 52ASC extension assembly, Cervélo EX14 carbon riser assembly, Cervélo SP23 carbon seatpost, FSA IS2 headset, front and rear thru axles, rear hydration mount, P5 stem storage, Smartpak top tube storage bag 400 and an aero water bottle with cage. Groupset, wheels and saddle are not included. TT positions are very fit-specific, so a proper bike fit is recommended - our team can help.
Specifications
Frameset
| Model | Cervélo P5 Frameset |
|---|---|
| Frame Material | Carbon |
| Fork | Cervélo All-Carbon, Bayonet P5 Fork |
| Brake Type | Disc |
| Aero Basebar | Cervélo HB15 Carbon, 38cm |
| Extensions | Profile Design 52ASC Extension Assembly |
| Riser | Cervélo EX14 Carbon |
| Seatpost | Cervélo SP23 Carbon |
| Headset | FSA IS2 1-1/8", 36° x 45° / 1-1/4", 45° x 45° |
| Front Axle | Cervélo Aero Thru Axle, M12x1.5mm, 127mm length |
| Rear Axle | Cervélo Aero Thru Axle, M12x1.5mm, 170.5mm length |
| Max Tyre Clearance | 34mm |
| Accessories | Rear hydration mount, P5 stem storage, Smartpak top tube storage bag 400, aero water bottle with cage |
| Available Sizes | 56 |
| Colour | Red Hot |
Geometry
| Measurement | 56 |
|---|---|
| Reach (mm) | 433 |
| Stack (mm) | 516 |
| Head Tube Angle | 72.5° |
| Front Centre (mm) | 622 |
| Bottom Bracket Drop (mm) | 75 |
| Head Tube Length (mm) | 106.9 |
| Standover Height (mm) | 792 |
| Wheel Size | 700C |
| Fork Offset (mm) | 43 |
| Wheelbase (mm) | 1015 |
| Chainstay Length (mm) | 405 |
| Effective Top Tube @ 75° Seat Tube (mm) | 571 |
| Effective Top Tube @ 79° Seat Tube (mm) | 533 |
