BMC Teammachine R 01 FOUR - Anthracite / Carbon
BMC Teammachine R 01 FOUR - Anthracite / Carbon
SKU: BMC-TMR4-BLK-51
Couldn't load pickup availability
Pick up in-store
Ships out (for delivery)
Calculating…
Delivery time depends on parcel size and destination pincode — you'll see an estimate at checkout. Choosing in-store pickup instead? See pickup availability above.
Racing Redefined: the ultimate race bike. From the cobbled Classics to one-day races, stage races, and criteriums, the Teammachine R 01 FOUR is built to win them all. Engineered in partnership with Red Bull Advanced Technologies, BMC's Impec lab has designed the Teammachine R 01 to go beyond the limits of a typical race bike, lightweight for the steepest climbs, aerodynamically optimised to slice through the wind, and stiff enough for exceptional power transfer. Equipped with a perfectly tuned Shimano Ultegra Di2 groupset, a precise 4iiii power meter, the seamless ICS Aero Carbon one-piece cockpit, and ultra-fast CR 50 SL wheels, the Teammachine R 01 FOUR delivers an unparalleled racing experience.
Specifications
| Frame | Teammachine R 01 | 01 Premium Carbon with Aerocore Design | ICS Technology Stealth Cable Routing | Stealth Dropout Design | Flat Mount Disc | 12 x 142mm Thru-Axle |
| Fork | Teammachine R 01 | 01 Premium Carbon | ICS Technology Stealth Cable Routing | Stealth Dropout Design | Flat Mount Disc | 12 x 100mm Thru-Axle |
| Handlebar | ICS Carbon Aero | One-Piece Full Carbon Cockpit | 135mm drop, 77mm reach, 12.5° flare |
| Seatpost | Teammachine R 01 | 01 Premium Carbon Seatpost | 10mm Offset |
| Saddle | Selle Italia SLR Boost Superflow | TI316 Rail | 145mm |
| Crankset | SHIMANO Ultegra (FC-R8100), 52-36T |
| Power Meter | 4iiii Precision Gen3+ Power Meter (Non-Drive Side) |
| Cassette | SHIMANO Ultegra (CS-R8101), 11-30T, 12-speed |
| Chain | SHIMANO CN-M8100 |
| Front/Rear Derailleur | SHIMANO Ultegra Di2 (FD-R8150 / RD-R8150) |
| Shifters | SHIMANO Ultegra Di2 (ST-R8170), 2 x 12 |
| Bottom Bracket | SHIMANO Ultegra Press-Fit Bottom Bracket (SM-BB72-41B) |
| Levers / Calipers | SHIMANO Ultegra (BR-R8170) |
| Rotors | SHIMANO Ultegra (RT-CL800) | 160/160mm |
| Rims | CR 50 SL Carbon | Tubeless Ready | 50mm |
| Hubs | TXC-812 & TXC-240 | Center Lock |
| Tyres | Pirelli P Zero Race TLR | 26mm | Tubeless Rim, Tubeless Tyres |
| In the Box | Aerocore Bottle Cages | Computer mount for Garmin and Wahoo |
| Bike weight | 7.5kg without pedals | Size 54 as pictured with all accessories |
| System weight limit | 110kg |
| Tyre clearance | 30mm measured tyre |
Specifications are subject to change without notice; compatible parts may be substituted due to supply chain issues.
Sizing and geometry
Rider height guide
| Size | 51 | 54 | 56 |
|---|---|---|---|
| Rider height | 166-174 cm | 172-180 cm | 178-186 cm |
Full geometry (mm unless noted)
| Size | 51 | 54 | 56 |
|---|---|---|---|
| Reach | 378 | 387 | 393 |
| Stack | 528 | 548 | 563 |
| Top Tube | 532 | 552 | 562 |
| Seat Tube | 463 | 499 | 519 |
| Head Tube | 133 | 149 | 165 |
| Head Tube Angle | 71.5° | 72.3° | 72.3° |
| Seat Angle | 74° | 73.5° | 73.5° |
| BB Drop | 69 | 69 | 69 |
| Chainstay (Rear Center) | 410 | 410 | 410 |
| Wheelbase | 986 | 989 | 999 |
| Front Center | 586 | 589 | 599 |
| Trail | 63 | 63 | 63 |
| Standover Height | 755 | 781 | 799 |
| Fork Rake | 48 | 43 | 43 |
| Fork Length | 367 | 367 | 367 |
| Crank Length | 170 | 172.5 | 172.5 |
| Stem Length | 100 | 100 | 110 |
| Stem Angle | -15° | -15° | -15° |
| Bar Width | 360/420 | 360/420 | 360/420 |
| Bar Drop / Reach | 135 / 77 | 135 / 77 | 135 / 77 |
| Seatpost Length | 335 | 385 | 385 |
| Seatpost Offset | 10 | 10 | 10 |
All measurements in mm unless stated otherwise. Data sourced from BMC's official geometry chart.
